Industrial Lasers

ILS12.75 Industrial Laser Engraver

The Industrial Laser is a line of high performance, large format, and fully customizable CO2 laser systems. The ILS12.75 incorporates a Pass-trough feature, which allows both side doors to be opened to process material that exceeds the length of the laser bed, or of unlimited length. The ILS12.75 CO2 laser system can be converted between CDRH Class 1 and CDRH Class 4.

The ILS12.75 is modular in design and upgradeable to meet your manufacturing and production needs. Features such as Laser Interface+ and Rapid Configuration; Dual Laser Configuration, Super Speed and Pass-Through are upgradeable features that help reduce downtime an increase productivity. Download brochure for more information.

ILS 9.75 Industrial Laser Engraver

The Industrial Laser is a line of high performance, large format, and fully customizable CO2 laser systems. The ILS9.75 incorporates a Pass-trough feature, which allows both side doors to be opened to process material that exceeds the length of the laser bed, or of unlimited length. The ILS9.75 CO2 laser system can be converted between CDRH Class 1 and CDRH Class 4.

The ILS9.75 is modular in design and upgradeable to meet your production needs. Features such as Laser Interface+ and Rapid Configuration; Dual Laser Configuration, Super Speed and Pass-Through are upgradeable features that help reduce downtime an increase productivity.Download brochure for more information.

Professional/Platforms

PLS6.150D w/ SuperSpeed Laser Engraver

High speed with maximum power.

PLS6.150 with SuperSpeed is designed for applications requiring high speed and maximum power flexibility. SuperSpeed allows for two lines of raster image to be marked simultaneously.

The PLS6.150D with SuperSpeed is suited for applications requiring both high-speed raster engraving and powerful vector cutting. Dual Configuration comes standard on the PLS6.150D with SuperSpeed. SuperSpeed pulses the two laser beans independently, making it possible for two lines of a raster image to be marked simultaneously. Download brochure for more information.

PLS6.150D Laser Engraver

Dual Laser Configuration

The PLS6.150D features Dual Laser Configuration for increased laser power when you need it. From 3D engraving to complex cutting and intricate scoring and marking, the PLS6.150D provides high speed and high quality.

Suited for production and manufacturing environments, the PLS6.150D features Dual Laser Configuration. The feature gives you the ability to merge two independent laser sources into a single beam for additional power and flexibility. Using two laser cartridges has advantages over a single higher power laser including better low-power stability. As an economical way to step into the PLS6.150D consider purchasing it with one laser. Download brochure for more information.

PLS6.75 Laser Engraver

Light manufacturing and batch production.

The PLS6.75 is the seasoned professional’s step up into high production laser processing. It is particularly suited for manufacturing and production environments.

Up to 75 watts of laser power and compatible with the production enhancing Dual Head, make the PLS6.75 capable of deep, high-speed engraving and thick cutting operations. The Universal features, such as Laser Interface+, 1-Touch Laser Photo, High Power Density Focusing Optics, and Rapid Reconfiguration make this laser engraver easy-to-use, and easily to integrate into your daily operations. Ideal for automotive, aerospace, electronics, manufacturing, medical, signage, awards, packaging and printing industry applications. Download brochure for more information.

PLS4.75 Laser Engraver

Small Scale Production and Prototyping.

The PLS4.75 delivers an impressive combination of size and performance. Capable of high speed and high throughput cutting and engraving, the PLS4.75 is compatible with lasers up to 75 watts.

An entry-level professional engraver from Universal Laser Systems, the PLS4.75 is designed for multi-material applications and small-scale production. The Universal features, such as Laser Interface+, 1-Touch Laser Photo, High Power Density Focusing Optics, and Rapid Reconfiguration make this laser engraver easy-to-use, and easily to integrate into your daily operations. Download brochure for more information.

PLS6MW Multi-Wavelength Laser Engraver

Rapidly switch between Fiber and CO2.

The PLS6MW is a cost-effective, small-footprint, that uses multiple laser wavelengths to process the broadest spectrum of materials in prototyping to production applications. Switch between fiber marking and CO2 marking and cutting applications.

The PLS6MW is engineered to support Universal’s lasers that produce 1.06 micron fiber/YAG wavelength light and 9.3 micron CO2 wavelength light, as well as Universal’s traditional CO2 lasers producing 10.6 micron wavelength light. Taking advantage of Rapid Reconfiguration, users can switch between wavelengths without tools and without realignment. Download brochure for more information.

VLS6.60 Laser Engraver

Fast. Productive. Versatile.

VLS6.60 laser engraver has a deep engraving area that can accommodate a variety of materials. The largest in the VLS platform line, the VLS6.60 is fast and productive.

The VLS6.60 is an excellent choice for on-demand personalization and prototyping of consumer electronics, accessories, and consumer merchandising for marketing focus groups. The Universal features, such as Laser Interface+ and 1-Touch Laser Photo, make this laser engraver easy-to-use, and easily to integrate into your daily operations. Download brochure for more information.

VLS4.60 Laser Engraver

Platform with Spacious Work Area.

The VLS4.60 is the intermediate size in the VLS product line with a larger engraving area that offers more space to fit larger pieces.

The VLS4.60 laser engraver offers a spacious work area and the ability to quickly adjust laser power with Universal’s patented Rapid Reconfiguration. With a laser power range of 10-60 watts, and the ability to quickly changes laser power makes the VLS4.60 ideal for light manufacturing and prototyping.
The Universal features, such as Laser Interface+ and 1-Touch Laser Photo, make this laser engraver easy-to-use, and easily to integrate into your daily operations. Download brochure for more information.

VLS3.60 Laser Engraver

Light-Duty Manufacturing Platform.

The VLS3.60 platform is the entry-point laser engraving machine for light-duty manufacturing. The VLS3.60 has been installed and utilized for educational institutions, architecture modeling, and product and graphic design.

The VLS3.60 laser engraving platform is a popular choice for light-duty manufacturing. The heavy-duty design and highly dependable laser engraving machine offers an engraving area that is highly sought out in the industry.
The Universal features, such as Laser Interface+ and 1-Touch Laser Photo, make this laser engraver easy-to-use, and easily to integrate into your daily operations. Download brochure for more information.

Desktop Lasers

VLS3.50 Laser Engraver

Compact. In-house Versatility.

The desktop VLS3.50 is the ideal entry-level laser engraving machine. It’s compact design makes it suitable for in-office or on the production floor when customized, low-run production is required.

Compact and powerful, the VLS3.50 desktop model from Universal Laser Systems is an ideal choice for on-demand production and prototyping in-house. The Universal features, such as Laser Interface+ and 1-Touch Laser Photo, make this laser engraver easy-to-use, and easily to integrate into your daily operations. The VLS3.50 is well suited to prototype development and on-demand production and also makes a capable second machine to handle production overflow. Download brochure for more information.

VLS2.30 Laser Engraver

Entry-level. Compact. Highly detailed.

The desktop VLS2.30 is the ideal entry-level laser engraving machine. The compact design makes it suitable for in-office or on the production floor when customized, low-run production is required.

The most compact and popular desktop model from Universal Laser Systems, the VLS2.30 provides the highest quality, while being a truly economical option for a laser system. The Universal features, such as Laser Interface+ and 1-Touch Laser Photo, make this laser engraver easy-to-use, and easily to integrate into your daily operations. The VLS2.30 is well suited to prototype development and on-demand production and also makes a capable second machine to handle production overflow. Download brochure for more information.
